The same 'circuit completion' (second diagram above) is necessary before the animal gets a shock. An animal standing on the ground and touching the electrified wires (shown right) will complete the circuit like the closed switch in the second diagram above.
For example, a bird sitting on the wire will not receive a shock (shown left). It is not touching the ground so the circuit is not completed. A person wearing insulated footwear will only receive a small shock because all the current cannot pass through the insulated soles.
Dry, sandy or pumice soil is a poor conductor of electric current, so it is a good idea to add an ground (negative) wire into the fence. The animal must touch both a hot wire and ground wire to feel an effective shock.
Once you have decided what type of electric fence you want for your property, you will need an energizer also known as a fence charger to power it. The correct energizer size for your property is determined by the type of animal to be fenced, distance of fence to be powered and the number of wires in the fence.
There are two types of energizers:
In this diagram the current cannot flow from the positive terminal to the negative terminal because the switch is open.
In this second diagram, the switch is now closed, allowing the current to flow from the positive terminal through the light bulb (lighting the bulb) to the negative terminal.
Grounding is perhaps the most neglected component of many fence systems. We recommend three ground rods, 6’ deep and spaced 10’ apart are the minimum recommendation. Never attach copper to steel. Electrolysis can occur and result in corrosion which weakens shocking power. Use galvanized ground wire and grounding rods to avoid this problem.
Consider that most energizers use galvanized or stainless steel terminals – not copper. Think of your ground system as an antenna that gathers electricity in order to deliver the shock to the animal. Modern satellite receivers can tune in to more television channels than the “rabbit ear” antennas of the past. A hose clamp holding a piece of copper wire to a rusty t-post has been the weakest link of many electric fence systems.
Will the electric netting work for free range poultry?
Yes, in most cases as long as the birds are clipped wing or are a non-flying species like Cornish. The netting will also act as a predator deterrent. It doesn’t take much of an energizer to contain a chicken, but a mid-range charger is needed if there is also a predator issue.
Fencing costs are one of the most expensive aspects of livestock grazing. The type of fence constructed greatly impacts the cost per foot, total cost, and annual ownership cost. In addition, the shape of the paddocks affects the amount of materials needed and labor required for construction of the fence.
This publication compares the costs of building a 1/4-mile (1,320 feet) straight perimeter fence with four different types of permanent fencing plus temporary interior fencing. These are: woven wire, barbed wire, high-tensile non-electric, high-tensile electrified, and temporary interior fencing.
The type of fencing selected varies by personal choice and the species of livestock to be confined. In general all configurations shown can be used with cattle, woven wire and high-tensile electrified can be used with sheep, and woven wire can be used with hogs.
The list of materials needed for each type of fencing is from Fencing Costs for Nebraska (see references at the end of the article). Costs were adjusted to 2005 prices provided by a number of Iowa retailers, although prices may vary. Labor was figured at $13.60 per hour, the average fence building labor charge reported in the 2005 Iowa Custom Rate Survey, FM-1698. Gates have not been included in the estimates.
