An electric fence circuit is made on a larger scale. The energizer fence terminal (positive) is connected to the insulated fence wires, and the energizer earth terminal (negative) is connected to galvanized metal stakes driven into the ground.

The same 'circuit completion' (second diagram above) is necessary before the animal gets a shock. An animal standing on the ground and touching the electrified wires (shown right) will complete the circuit like the closed switch in the second diagram above.

For example, a bird sitting on the wire will not receive a shock (shown left). It is not touching the ground so the circuit is not completed.  A person wearing insulated footwear will only receive a small shock because all the current cannot pass through the insulated soles.

​​

Dry, sandy or pumice soil is a poor conductor of electric current, so it is a good idea to add an ground (negative) wire into the fence. The animal must touch both a hot wire and ground wire to feel an effective shock.

Choosing the Right Energizer (Fence Charger)

Once you have decided what type of electric fence you want for your property, you will need an energizer also known as a fence charger to power it.  The ​correct energizer size for your property is determined by the type of animal to be fenced, distance of fence to be powered and the number of wires in the fence.

There are two types of energizers:

• Mains powered - these are energizer units which are plugged into a mains power supply.
• Battery/Solar powered - these are energizer units which can be left out in your paddock and require a battery to run them. Two batteries can be rotated on a regular basis or a solar panel can be an effective means of continuously charging your battery.

Electric current (AMPS) only flows when a circuit is completed between a positive and negative terminal.

In this diagram the current cannot flow from the positive terminal to the negative terminal because the switch is open.

In this second diagram, the switch is now closed, allowing the current to flow from the positive terminal through the light bulb (lighting the bulb) to the negative terminal.


Steps to Good Grounding

Grounding is perhaps the most neglected component of many fence systems. We recommend three ground rods, 6’ deep and spaced 10’ apart are the minimum recommendation. Never attach copper to steel. Electrolysis can occur and result in corrosion which weakens shocking power. Use galvanized ground wire and grounding rods to avoid this problem.

Consider that most energizers use galvanized or stainless steel terminals – not copper. Think of your ground system as an antenna that gathers electricity in order to deliver the shock to the animal. Modern satellite receivers can tune in to more television channels than the “rabbit ear” antennas of the past. A hose clamp holding a piece of copper wire to a rusty t-post has been the weakest link of many electric fence systems.​​
